KORAWALL WI - convectors with forced convection

EN-Korawall Wednesday, 27 September 2017 09:20
Rate this item
(0 votes)



Developed for low temperature heating systems, high efficiency guaranteed also at very low temperature gradients, e.g. 35/30 °C. Ideal everywhere where the heat source is a heat pump, a solar system, a condensation boiler or as a supplementary source of heat for fl oor heating, particularly during a transitional period or when an instant temperature increase in the room is required. At the same time suitable for rooms' dry-cooling during the summer months. All of this with the benefi ts of the Optimized Convection system – low noise and low fan input while maintaining maximally attainable performances.

Univeral use – heating and dry-cooling!

Wall-mounted convector with forced convection KORAWAL WI 45/11

height 45 cm, depth 11 cm
  • used for heating or dry-cooling
  • high efficiency even at low temperatures of the heating system
  • patented design solutions
  • high-perfomance, low energy and quiet fans
  • the same regulation as the one for floor convectors KORAFLEX FV and free standing convector with forced convection KORALINE LV
  • two-pipe system
  • right bottom connection
  •  possibility of control through BMS
  • the convector is intended for dry environment



Additional Info

  • Depth (mm): 106
  • Height (mm): 450
  • Length (mm): 750 - 2000 (at 250 mm steps)
  • Heat output (W): 106
  • Exchanger height (mm): 240
  • Exchanger width (mm): 100
  • Fans impeller diameter (mm): 60
  • Connection to the rating system: inner G 1/2“
  • Types of Connection: recommended bottom connection, right



Read 373 times Last modified on Wednesday, 27 September 2017 09:35
